Wrie Rope Winch Double or Four Drums Can Be Customized Electric
Power Winch
Product introduce :
| name | Wrie Rope Winch Double or Four Drums Can Be Customized Electric
Power Winch |
| Hoist speed | 0.95-1.27m/s |
| Rotate speed | 720-960 r/min |
| Rope diameter | 3-30mm |
| Sling type | wire |
| Direction rotation | left or right |
| Application | hoist |
| Parameter | can be designed |
| Application | mining,oil drilling,or coal mine |
| Drum diameter | 900mm |
| Drum width | 600mm |
Application:
The Electric Power Winch of this series are used to lift materials,
equipments and people in coal mine, iron mine, metal mine and non
metal mine inclined roadway and small shaft.
Working Principle:
The motor transmits power to the winding drum wrapped by wire rope
through the reducer to lift and lower the container, reduce the
speed through electric drive. Disk break is controlled by hydraulic
pressure and electric; Position indicator system shows the depth of
the container; the control system integrating the motor, electric
and hydraulic pressure supervises and protects the whole equipment
through a variety of sensors and control elements; Internal and
external information transmission is carried out by the computer
and the internet technology.
Technical Features:
1. We adopt integral, two-part and four-part drums.
2. The rope drum adopts the spiral rope groove or LBS grooves
pressed by engineering lining plastic, with steel sling set as
transition device.
3. Adopt the rear oil cylinder disc brake controlled by electric
and hydraulic pressure; the hydraulic pressure station divides into
two types – medium voltage and high voltage. Medium voltage station
has two methods of braking – holding brake force and hydraulic
delay; Medium and high voltage station has two types – the constant
deceleration and the constant braking torque. Hydraulic pressure
station is equipped with the pressure sensor and the pressure
relay.
Electric winch basic structure
Due to the different operation methods of electric winch, its
structure is very different. We divide it into electronic hoist and
slip type hoist two kinds.
Electric Winch
This type of winch through electricity or power to achieve the work
of the winch or brake. Material lifting or falling by the motor
forward and reverse to achieve, simple and convenient operation.
Its brake type mainly has the electromagnet brake and the conical
rotor motor two kinds, the following two kinds of brake type hoist
is introduced. This type of winch is mostly single drum.
A hoist with an electric roller brake
Information required for quotation
In order to provide accurate quotation for LBS rope groove drum,
the user shall provide the following parameters:
1. Company Name:
2. Contact person:
3. Contact Information: Mobile phone:
4. Email Address:
5. Drum diameter: mm
6. Width between flannels: mm
7. Diameter of wire rope or cable: mm
8. Reel material and requirements:
9. Maximum rope capacity of wire rope or cable: M
10. Position Angle of reel and fixed pulley:
11. Entry direction of wire rope or cable (LBS rope groove
rotation) : left: right:
12. Flange diameter: mm
Maximum working load of wire rope or cable:
14. Whether to provide detailed drum drawings:
15. Rope way, through the flange or through the main barrel:
16. Other information and requirements:
