Hydraulic Drive Wire Rope Tower Crane Winch Lifting Winch Lebus
Groove Drum Customized Design
.Tower crane winch
Tower crane is referred to as tower crane, also known as tower
crane, originated in Western Europe. A rotating crane with arms
mounted on top of a towering tower. Large working space is mainly
used for vertical and horizontal conveying of materials and
installation of building components in building construction. It is
composed of metal structure, working mechanism and electrical
system. The metal structure includes tower body, boom and base. The
working mechanism has four parts: lifting, luffing, turning and
walking. Electrical system includes motor, controller, power
distribution cabinet, connecting circuit, signal and lighting
device, etc
Product structure
Hydraulic winch is usually combined with hydraulic motor, control
valves, gear boxes, grooved drum, brackets (clutch), pressure rope
and mounting brackets.
Advantages of LEBUS groove
Double folding rope groove makes the wire rope winding smooth, load
evenly distributed between each layer, practice has proved that
this technology greatly prolongs the service life of wire rope,
data shows that can prolong the life of wire rope more than 500%,
reduce wire rope damage, improve safety, and reduce the mechanical
equipment for rope replacement downtime
.
Product specification
Custom-made (according to actual )
Pay more attention to your choose
We suggest your choose the LBS drum design .As it can save time and
money for your in the future use .As the LBS design have its
specail design for two parallel and two spiral lsection in one
layer that can make the rope on its regular track and working
smoothly than the traditional design .That can improve your working
efficency.
Products Parameter
product name | Hydraulic Drive Lebus Grooved Wire Rope Tower Crane Winch For
Lifting Object |
| Usage | tower crane ,offshore platform |
| Winch drum type | suggest LBS (smooth or traditional spiral ) |
| Fuction | lifting,hoist,pulling |
| Field | offshore,crane ,marine,oil drilling,mining |
| Wire rope diameter | 3~199mm |
| Wire rope capacity | 100-1000M |
| Colour | red or customer |
| Orignal | China(mainland) |
| Load capacity | 1-60KN |
| Rope speed | 0-40m/min |
| Power | hydraulic or customer |
Some products type parameter for your reference:that can be design
to meet requirement
| Model | Layer plly force (T) | Rope speed | Drum bottom diameter | Difference of working pressures(Mpa) | Rope capaticty(mm) | Diameter of steel cable(mm) | Model of power |
| LBSTC1-10 | 30 | 0-35 | 305 | 15.9 | 65 | 15 | XH2-420 D51 |
| LBSTC1-20 | 50 | 0-40 | 380 | 16.3 | 70 | 20 | XH3-900 D240 101 |
| LBSTC1-30 | 80 | 0-40 | 470 | 15.6 | 100 | 24 | XH5-1800 D240101 |
| LBSTC1-40 | 100 | 0-40 | 470 | 16 | 90 | 28 | XH6-2000 D240 101 |
| LBS0F1-50 | 120 | 0-30 | 600 | 17.3 | 175 | 30 | XH6-3000 D240101 |
| LBSTC1-60 | 150 | 0-30 | 640 | 17.8 | 143 | 38 | XH7-4300 D240101 |
| LBS TC1-70 | 200 | 0-25 | 660 | 17.8 | 150 | 40 | XH8-900d240101 |
Product Feature
1) Two-or three-stage planetary gearboxes, smooth operation and
reasonable structure.
2) High efficiency of starting and transmissing, low energy
consumption, reliable operation and long service life.
3) Highly efficient, constant operating torque motor.
4) Smooth running over the entire speed range.
5) Axial fixed or variable hydraulic motor with long life
operating.
6) Mounting frame is available on request.
7) Low noise operation.
Product advantage
Our factory mainly in the service of hoisting machinery, Marine
machinery, petroleum machinery, hydraulic machinery, engineering
machinery and other industries, the main products are oil drilling
rig, workover rig, drifting machine, trailermounted pumping unit
winch (The main drum is used LBS grooved drum) and oil equipment
accessories.
