Steel Wrie Rope Winding Single Or Doubler Drum For Electric Cable Pulling Winch

Introduction to pulling winch

The pulling winch consists of several parts, which are connected in series by wire rope. The working principle is to drive the whole system by the friction between the friction wheel and the wire rope, and the friction wheel is connected with the drive device. Generally, the width of the winch is within 1.5 m, which ensures the compactness and reliability of the entire transport unit. The traction winch is provided with tensioning device

We also supply LBS grooved drum used in all kinds of winchs. The whole drum details as follows:

1. the groove is cut directly into the body of drum.

2. according to the customer' requirements, the flanges are either welded or screw-bolted.

3. the groove is available as either LBS-groove or helical-groove.

4. groove geometry is determined by rope construction, diameter and length ,and by application.

5. the drum is provided with the requested mounting dimensions to fit the flanges by welding or screw bolting.

Sleeves are used to prevent damage to a drum. It is usually cheaper to replace a worn out sleeve in stead of replacing or repair the complete drum assembly.

The LBS split-sleeve system consists of a pair of outer shells that are bolted or welded onto a smooth drum to provide a grooving pattern. either LBS parallel grooves can be carved into sleeves. As with all LBS drums, the grooving in split sleeves is engineer to much the specific rope construction, diameter and length, and to suit

Steel Wrie Rope Winding Single Or Doubler Drum For Electric Cable Pulling Winch

We can design the LBS sleeve according to the drum's size and parameter.So the customer need to provide some paramter as follows:

Hebei Junke Machinery Techonlogy Co., Ltd was established in 2010. Now it is located in Shijiazhuang city, Hebei province, China. Our company covers more than 10000 square meters and it has very convenient transportation. There are more than 300 existing staff members  among who are 100 profressional technicists. We also have skilled workers and advanced processing equipments.

Our factory has more than 2000 sets of casting, forging, gear machining, sheet metal stamping, welding, heat treatment,machining and other advanced equipments. In recent years, we have introduced 80 machines of Germany CW1000 processing center, CNC four axis,five-axis linkage machining center, CNC punching machine,large CNC gear hobbing gear grinding machine, large CNC floor-type boring and milling machine, vacuum electron beam welding, CNC welding robots and other advanced processing equipments.

Our factory always adhere to business idea of "Honesty and Credibility＆Customer First". With high reputation, high quality products and a competitive price policy ,we provide our customers with satisfactory services.

We hope to establish long-term and stable business cooperation with domestic and foreign customers!
