Customizble Tower Crane Drawworks Wire Rope Winch Drum Lebus Groove

Cutomizble Tower Crane Drawworks Wire Rope Winch Drum LEBUS Sleeve

Product Introduction

Materials of the sleeves: Low-carbon steel 20#,16Mn,Q235B,Q355B/D/E

The use the sleeves: Welded or bolted to the smooth drum core of the winch

Rotation direction of the sleeves: Left or Right

Processing equipment: CNC machining center

Working environment: Indoor, outdoor, rain and dust environment

Working altitude: No more than 2000M

Working Temperature: -40~+50 CentigradWelded or bolted to the smooth drum core of the winch

Product include:

Split-type grooved sleeves
Integrated type grooved sleeves

. the complete drum with flanges,machine-finished

the groove is cut directly into the body of the drum
according to customers' requirements,the flanges are either welded or screw-bolted
the groove is available as either LBS-groove or helical-groove
groove geometry is determined by rope construction,diameter and length and by application.
the drum is provided with the requested mounting dimensions to the fit the flanges by welding or screw bolting.

Breif Description:

The LBS split-sleeve system is composed of a pair of outer shells that are bolted or welded onto a smooth drum to provide agrooving pattern.Either helical or LBS parallel grooves can be carved into the sleeves.

If the customer need split-sleeves, please provide us with more parameter details as follows:

1. about grooving	helical or LBS grooving
2. drum diameter and length	the sleeve must according to the drum parameter
3. rope diameter and length	the grooving desiged by the rope parameter
4. Material	your required material
5. installation	bolted or welding
6. more information	the detailed drawing if possible

Product advantage:

Compared with the general non grooved (smooth) drum and spiral grooved drum, the Grooved Steel Drum Sleeves has obvious advantages in the neat winding of multi-layer steel wire rope. Lbs double fold rope groove makes the winding of steel wire rope more smooth and the load between layers is evenly distributed, reduces the irregular, disorderly winding and rope biting in the process of steel wire rope arrangement, reduces the damage of steel wire rope, prolongs the service life of steel wire rope, improves the safety of equipment operation, and avoids the shutdown time of mechanical equipment due to disorderly rope replacement.

Technical parameters and application:

No:	Wire diameter(mm):	Rotation direction	Main drum diameter(mm)	Main drum length(mm)	Application
1	8 10 13	Lefthand,Righthand	430	763	The oil workover rig winch, Towing winch Tower crane
2	13 18 20	Lefthand,Righthand	623	1144	Engineering winch, Lifting winch,Crawler crane
3	22 25 26	Lefthand,Righthand	730	1220	Oil workover rig , Logging Winch
4	18 22 32	Lefthand,Righthand	670	1240	Drilling Rig Winch, drawworks
5	28 32 36 40	Lefthand,Righthand	560	630	Rotating Drilling Rig winch, Lifting equipment
6	26 28 32 45	Lefthand,Righthand	760 1146	1970 1765	Offshore Crane, Marine crane,Mooring winch
