Lifting Equipment Wire Rope Stainles Steel Lebus Grooved Mine Host
Drum
Mine hoist drum
Mine winch is also called mine hoist, mine hoist, in the mine is
very important equipment, is the throat of the mine.
The winch with drum diameter of 1.2 m and 1.6 m is called JTP- mine
hoist;
Drum diameter of 2.0 meters, 2.5 meters, 3.0 meters, 3.5 meters and
4 meters and 6 meters diameter of more than 2 meters is known as JK
mine hoist;
There are also some small winches mainly used for drift traction,
not for the main lift are 0.4 m, 0.5 m, 0.6 m, 0.8 m.
Oerview
Winch drum is an important part of oil rig winch, winch drum
One end of the wound wire rope is fixed at the drum rope socket
through a rope clip, and the other end
The guide wheel of the sky car is introduced into the trolley
pulley group, and the trolley pulley group is installed
Equipped with hooks, faucets and drill pipe strings. When the winch
works, it is wound
The steel wire rope on the drum realizes the action of winding and
releasing the rope through positive and negative rotation of the
drum
The drum bears the fast rope tension of the wire rope, and the drum
structure must meet the strength
Outside, but also to ensure that the wire rope winding neatly.
LEBUS rope groove
With the development of oil drilling winches in recent decades,
winches appear more
The transmission form and the structure form, but the winding rope
rule of the winch drum is not
Change, our company developed LEBUS rope groove has obvious
advantages. LEBUS rope groove
Double line form, suitable for multi-layer winding, can effectively
reduce or avoid steel wire
Rope disorder phenomenon. In the design process of the drawworks
drum, the drawworks drum has a large opening range
Small, bottom diameter selection, position of guide block, rope
socket structure, rope groove spacing, rope groove
The spiral Angle of the parallel section and the climbing section
will affect the effect of drum rope winding, because
This, the study of winch drum structure and characteristics, will
help to reduce or avoid
Oil field field hoist drum disorderly rope phenomenon, prolong the
use of wire rope and drum
Life.
Product Introduction
Grooved Winch Drum Material: Carbon Steel, Alloy Steel, Stainless
Steel, Aluminum, High-Strength Steel, Etc
Material Standards: GB, AISI, ASME, ASTM, JIS, DIN, ...
Ambient Temperature: -40 ° C To +45 ° C
Stroage Ambient Temperature: -40 ° C To +50 ° C
Groove Type of Drum: Spiral Grooves or Lebus Grooves
The Rotation Direction of The Drum: Lefthand or Righthand
Processing method: Machine Work
Wire Rope Diameter: 3 MM~100 MM
Processing Equipment: CNC machining center
Technical Parameters
| No: | Wire diameter(mm) | Pulling Force(KN) | Rotation Direction | Drum Diameter(mm) | Drum Length(mm) |
| 1 | 3~8 | 3~10 | Lefthand,Righthand | >160 | <1000 |
| 2 | 10~16 | 12~20 | Lefthand,Righthand | >320 | <1000 |
| 3 | 18~24 | 20~80 | Lefthand,Righthand | >480 | <1000 |
| 4 | 26~32 | 100~120 | Lefthand,Righthand | >640 | <1000 |
| 5 | 34~40 | 150~200 | Lefthand,Righthand | >800 | <1000 |
| 6 | 42~50 | 240~400 | Lefthand,Righthand | >1000 | <1000 |
Product information
| The name | Lifting Equipment Wire Rope Stainles Steel Lebus Grooved Mine Host
Drum |
| Hoist speed | 0.95-1.27m/s |
| Rotate speed | 720-960 r/min |
| Rope diameter | 3-30mm |
| Sling type | wire |
| Direction rotation | left or right |
| Application | hoist |
| Parameter | can be designed |
| Application | mining,oil drilling,or coal mine |
| Drum diameter | 900mm |
| Drum width | 600mm |
Information required for quotation
In order to provide accurate quotation for LBS rope groove drum,
the user shall provide the following parameters:
1. Company Name:
2. Contact person:
3. Contact Information: Mobile phone:
4. Email Address:
5. Drum diameter: mm
6. Width between flannels: mm
7. Diameter of wire rope or cable: mm
8. Reel material and requirements:
9. Maximum rope capacity of wire rope or cable: M
10. Position Angle of reel and fixed pulley:
11. Entry direction of wire rope or cable (LBS rope groove
rotation) : left: right:
12. Flange diameter: mm
Maximum working load of wire rope or cable:
14. Whether to provide detailed drum drawings:
15. Rope way, through the flange or through the main barrel:
16. Other information and requirements:
