Steel Material Lebus Grooved Winch For Desert Oil Rig Drawworks
Company introduction
Shijiazhuang JunZhong Machinery Manufacturing Co.,Ltd. specializing
in the production of lebus grooved drum. we have own brand LBS,
with introduction of domestic and foreign advanced technology and
experience, after years of research and development, we are now
strong in the multi-layers rope grooved drum area and awarded
patent by country having a high reputation in that area.
Our factory has more than 2000 sets of advanced equipment such as
casting, forging, gear processing, sheet metal stamping, riveting,
heat
treatment and mechanical processing. In recent years, the Germany
CW1000 machining center, CNC four axis, five axis linkage machining
center, CNC punch, large CNC hobbing gear grinding machine, large
CNC floor boring and milling machine, Vacuum electron beam welding,
CNC welding robot and 80 roll machine and other advanced processing
equipment.
description:
colour :red or require
Sling type:cable or wire
Power :electric or hydraulic
Rope capacity:1~10000m
Rope diameter:3~90MM
Winch drum type:LBS groove
Customization need more product technical parameters.
Drum features:
Product adoption LBS grooved drum, LBS groove system makes the
winding of wire rope smooth, and the load of each layer evenly
distributed,the technology greatly prolong the service life of wire
rope, reduce the wire rope damage, improves the safety of the
operation of the equipment, and reduces the problem of mechanical
equipment shutdown for changing rope.
Techinical parameters:
| technical parameters |
| input powerkW | JZ05 | JZ03 | JZ10-2 | JZ08-02 | JZ02-09 | JZ3-2 | JZ50D |
| 150 | 180 | 400 | 450 | 600 | 735 | 1100 |
| master rotor | Maximum Fast line tension(second floor)kN | 80 | 120 | 180 | 210 | 280 | 275 | 340 |
|
|
| diameter of the tube body x lengthmm | Φ345×590 | Φ356×912 | Φ450×912 | Φ450×912 | Φ580×1012 | Φ640×1237 | Φ685×1138 |
| brake drum (disc) diameter x length (thickness)mm | Φ810×210 | Φ970×260 | Φ1070×310 | Φ1070×310 | Φ1168×267 | Φ1168×265 | Φ1600×76 |
| For wire rope diameter mm | 22 | 22 | 29 | 29 | 32 | 32 | 35 |
| maximum speed of revolutionrpm | 450 | 450 | 450 | 450 | 450 | 370 | 370 |
| brake drum cooling way | air cooling | air cooling | Forced circulating water cooling | Forced circulating water cooling | Forced circulating water cooling | Forced circulating water cooling | air cooling |
About us:
Shijiazhuang Jun Zhong Machinery Maufacturing Co.,Ltd has been certified as “High & New-tech Enterprises of Hebei
Province”, “benchmark enterprises”, “Well-known Trademark of
China”, “Famous Trademark of Hebei Province”, and it has achieved
many patents of state level and National Torch Plan Projects.
