Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks
Oil Rig Drawworks information
Usage: Oil Well
Applicable Industries: Energy & Mining
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: New Product 2020
Warranty of core components: 1 Year
Core Components: Engine, Motor, Pump
Condition: New
Type: Rotary Drilling Rig
Power Type: Electric or Hydraulic
Place of Origin: China
Brand Name: LBS
Model Number: 750HP -900HP drilling rig
Voltage: 380V
Warranty: 1 Year
Product name: Drilling Rig
Application: Oil Drilling Rig
Drilling Depth: 1000-9000 meters
Classfication: Electrical/Mecahnical/Mechan-Electrical Rig
Model: 750HP-3000HP Rig
Key words: Drilling Rig/Workover
Product Category: as per customer's requirement
Engine: Electric Or Hydraulic
Meterial: Steel
Drum features
Product adoption LBS grooved drum, LBS groove system makes the
winding of wire rope smooth, and the load of each layer evenly
distributed,the technology greatly prolong the service life of wire
rope, reduce the wire rope damage, improves the safety of the
operation of the equipment, and reduces the problem of mechanical
equipment shutdown for changing rope.
Techinical parameters
| technical parameters |
| input power(kW) | JZ05 | JZ03 | JZ10-2 | JZ08-02 | JZ02-09 | JZ3-2 | JZ50D |
| 150 | 180 | 400 | 450 | 600 | 735 | 1100 |
| master rotor | Maximum Fast line tension(second floor)kN | 80 | 120 | 180 | 210 | 280 | 275 | 340 |
|
|
| diameter of the tube body x lengthmm | Φ345×590 | Φ356×912 | Φ450×912 | Φ450×912 | Φ580×1012 | Φ640×1237 | Φ685×1138 |
| brake drum (disc) diameter x length (thickness)mm | Φ810×210 | Φ970×260 | Φ1070×310 | Φ1070×310 | Φ1168×267 | Φ1168×265 | Φ1600×76 |
| For wire rope diameter mm | 22 | 22 | 29 | 29 | 32 | 32 | 35 |
| maximum speed of revolutionrpm | 450 | 450 | 450 | 450 | 450 | 370 | 370 |
| brake drum cooling way | air cooling | air cooling | Forced circulating water cooling | Forced circulating water cooling | Forced circulating water cooling | Forced circulating water cooling | air cooling |
