Onshore Large Oil Rig Drawworks Electric Drilling With CCS Certification

Ask Lasest Price
Brand Name :	LBS
Model Number :	customizable
Certification :	CCS
Price :	Negotiation
Payment Terms :	L/C, T/T
Supply Ability :	150 sets per month
Delivery Time :	20 to 30 working days, depends on order amount and specification

Add to Cart

Product Details
Company Profile

Onshore Large Oil Rig Drawworks Electric Drilling With CCS Certification

High Quality Cost-Effective Electric Drilling Onshore Large Oil Rig Drawworks

Product information

Usage: Oil Well

Applicable Industries: Energy & Mining

Video outgoing-inspection: Provided

Machinery Test Report: Provided

Marketing Type: New Product 2020

Warranty of core components: 1 Year

Core Components: Engine, Motor, Pump

Condition: New

Type: Rotary Drilling Rig

Power Type:Electric or Hydraulic

Place of Origin: China

Brand Name: LBS

Model Number:750HP -900HP drilling rig

Voltage: 380V

Warranty: 1 Year

Product name: Drilling Rig

Application: Oil Drilling Rig

Drilling Depth: 1000-9000 meters

Classfication: Electrical/Mecahnical/Mechan-Electrical Rig

Model: 750HP-3000HP Rig

Key words: Drilling Rig/Workover

Product Category: as per customer's requirement

Engine: Electric Or Hydraulic

Meterial: Steel

After-sales Service Provided: Online support, Video technical support, Field installation, commissioning and training, Field maintenance and repair service

Certification: CCS

colour :red or require

Sling type:cable or wire

Power :electric or hydraulic

Rope capacity:1~10000m

Rope diameter:3~90MM

Winch drum type:LBS groove

Customization need more product technical parameters.

Drum features:

Product adoption LBS grooved drum, LBS groove system makes the winding of wire rope smooth, and the load of each layer evenly distributed,the technology greatly prolong the service life of wire rope, reduce the wire rope damage, improves the safety of the operation of the equipment, and reduces the problem of mechanical equipment shutdown for changing rope.High quality Cost-effective Electric Drilling Onshore Large Load Workover Rig

Techinical parameters:

technical parameters
input powerkW		JZ05	JZ03	JZ10-2	JZ08-02	JZ02-09	JZ3-2	JZ50D
input powerkW		150	180	400	450	600	735	1100
master rotor	Maximum Fast line tension(second floor)kN	80	120	180	210	280	275	340


	diameter of the tube body x lengthmm	Φ345×590	Φ356×912	Φ450×912	Φ450×912	Φ580×1012	Φ640×1237	Φ685×1138
	brake drum (disc) diameter x length (thickness)mm	Φ810×210	Φ970×260	Φ1070×310	Φ1070×310	Φ1168×267	Φ1168×265	Φ1600×76
	For wire rope diameter mm	22	22	29	29	32	32	35
	maximum speed of revolutionrpm	450	450	450	450	450	370	370
	brake drum cooling way	air cooling	air cooling	Forced circulating water cooling	Forced circulating water cooling	Forced circulating water cooling	Forced circulating water cooling	air cooling

High Quality Cost-Effective Electric Drilling Onshore Large Oil Rig Drawworks

About us:

Shijiazhuang Jun Zhong Machinery Maufacturing Co.,Ltd has been certified as “High & New-tech Enterprises of Hebei Province”, “benchmark enterprises”, “Well-known Trademark of China”, “Famous Trademark of Hebei Province”, and it has achieved many patents of state level and National Torch Plan Projects.
