Lifting Equipment 10mm Diameter Cable Smooth Drum Used For Elctric
Power Winch
overview
Cable winch is an essential part of the construction products such
as underground cable lines and vertical rods, which can be
conveniently used in various complex environments for smooth
erection of wire hanging, pulling or tightening.
Cable winch is composed of drum, gearbox, diesel engine or gasoline
engine and base.
| Product name | Cable winch drum |
| Drum Quantity | Single Or Double |
| Drum Design | LBS Groove Or Spiral Groove |
| Material | Carbon Stainless And Alloy Steels |
| Size | Customization |
| Application Range | Construction Mining Terminal operation |
| Power Source | Electric and hydraulic |
| Rope Capacity | 100~300M |
| |
Product specifications:
1) Wire rope or cable diameter (mm)
2) The main drum diameter (mm)
3) Width between flanges (mm)
4) Length of rope or cable to be accommodated
5) Material and requirements of the drum
6) Maximum operating load on rope or cable
7) Direction of wire rope entry
8) Type of rope entry
9) Distance to fixed sheave and position between flanges
10) Outside diameter of flanges
Processing equipment:
CNC machining center
Product material:
1. Carbon structural steel: Q235A/B/C/D/E SS400 A36 SM400 St37-2
S235J...
2. Low alloy high strength steel: Q345A/B/C/D/E Q390 Q420 Q460
15GrMo 20GrMo 12GrMoVNi 42GrMo...
3. Alloy structural steel: 20Mn2 40Mn2 15Cr 30Cr 20CrMnMo 20CrNi...
4. Polymer materials, fiber materials and polyamide nylon
materials.
5. Stainless steel materials, aluminum materials, etc.
The product material can be selected according to the customer's
request
Drawing dimensions
Drum features:
Processing Equipment: CNC Machining Center
Rotation Direction Of Grooves: Lefthand
Wire Rope Diameter: 3 MM~65 MM
Each Layer Laps: 20.5 laps
Layer: 5 Layer
Rope Groove Type: LEBUS Rope Groove
Number Of Ropes: Two
Our company
Shijiazhuang Junzhong Machinery Manufacturing Co., Ltd. was
established in 2010 with a registered capital of 18 million yuan.
The company is a long-term engaged in cable retracting system of
scientific and technological production enterprises in the
multi-layer winding of wire rope has a profound foundation and
production experience.
As early as 2010, the company obtained the utility model patent
certificate suitable for multi-layer winding double folding cable
groove, and registered the LBS trademark in 2013.
Passed iso9001:2015 quality management system certification in
2017;
In 2018, it passed the GJB9001C-2017 weapon equipment quality
management system certification.
In 2019, the company was identified as a science and technology
smes in Hebei Province.
In recent years, the company with strong technical strength,
advanced production equipment, strict quality control system,
achieved rapid development.
Product Equiment
Our factory has more than 2000 sets of advanced equipment such as
casting, forging, gear processing, sheet metal stamping, riveting,
heat treatment and mechanical processing. In recent years, the
Germany CW1000 machining center, CNC four axis, five axis linkage
machining center, CNC punch, large CNC hobbing gear grinding
machine, large CNC floor boring and milling machine, Vacuum
electron beam welding, CNC welding robot and 80 roll machine and
other advanced processing equipment
Required Parameters
Wire rope diameter or cable diameter(mm)
Inner diameter D1(mm)
Outer diameter D2(mm)
Width between the flanges L(mm)
Rope capacity(m)
Material:
Rotation direction:left or right?
