    Customized Alloy Steel Material Hydraulic Grooved Winch Drum

    Ask Lasest Price
    Brand Name : LBS
    Model Number : LBSD Series
    Certification : CCS, ABS
    Price : USD, EUR, RMB / Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 Pieces Per Month
    Delivery Time : General Order 15-30 Days
    • Product Details
    • Company Profile

    Customized Alloy Steel Material Hydraulic Grooved Winch Drum

    Alloy Steel Material Hydraulic Winch With Grooved Drum, Can Be Customized

    Features

    1. Capacity: 1-65T

    2. Lifting height: 2400m

    3. Lifting speed: single/VVVF

    4. Power: hydraulic motor

    5. Top quality with competitive price.

    6. Easy to install and high quality.

    7. Compact structure and reasonable design.

    8. Widely used in mining and marine


    Product infromation
    The nameAlloy Steel Material Hydraulic Winch With Grooved Drum Can Be Customized
    Hoist speed0.95-1.27m/s
    Rotate speed720-960 r/min
    Rope diameter3-30mm
    Sling typewire rope
    Direction rotationleft or right
    Applicationhoist
    Parametercan be designed
    ApplicationWindow Cleanere
    Drum diameter400mm~500mm
    Drum width1000mm

    Technical Parameters

    No:Wire diameter(mm)Pulling Force(KN)Rotation DirectionDrum Diameter(mm)Drum Length(mm)
    13~83~10Lefthand,Righthand>160<1000
    210~1612~20Lefthand,Righthand>320<1000
    318~2420~80Lefthand,Righthand>480<1000
    426~32100~120Lefthand,Righthand>640<1000
    534~40150~200Lefthand,Righthand>800<1000
    642~50240~400Lefthand,Righthand>1000<1000

    LeBUS rope groove specifications:

    Custom design or processing according to drawings.
    Lebus rope groove drum is divided into integral and split, integral needs to process drawings.
    The separation needs parameters such as drum diameter, outer diameter, length, wire rope diameter, rope groove rotation (left or right) and so on.
