Large Rope Capacity Electric Marine Winch Multilayer Winding With Lebus Groove

Large Rope Capacity Multi-Layer Winding Electric Winch With LEBUS Groove For Marine

Product feature

Product name: Large Rope Capacity Multi-Layer Winding Electric Winch With LEBUS Groove For Marine

other name: Electric Marine winch

Drum design: Lebus grooved

Sling type: Wire rope

power: Electirc

Rope capacity: 1000m

Rope diameter: 60mm

colour: Blue or customer

Product Structure

Groove Drum Composition: Drum core, Flanges, Shaft, Etc.
Processing: Rope drums with grooves cut directly into them.Winch drum with flange, the LBS groove is cut directly into the body of the drum, according to customers’ requirements, the flanges are either welded or screw-bolted. groove geometry is determined by rope construction, diameter and length, and by application. the drum has the required mounting dimensions for the actual operating conditions.

LBS Drum required parameters

Sleeve Diameter of wire rope or cable
Diameter of smooth drum (inside diameter of rope groove)
Outer diameter of rope groove drum
Length between drum flanges
Rope capacity
Rope groove rotation (left or right)
LBS drum leather material required

Techinical parameters

Technical Parameters of LBS-J Slow Speed Electric Winch
Model	Rated	Rated	Rope	Rope	Motor	Motor	Overall	Overall
Model	load	speed	capacity	diameter	type	power	Dimensions	weight
	KN	m/min	m	mm		KW	mm	KG
LBS-J1	10	15	100	9.3	Y112M-6	3	620x701x417	270
LBS-J1.6	16	16	150	12.5	Y132M-6	5.5	945x996x570	500
LBS-J2	20	16	150	13	Y160M-6	7.5	945x996x570	550
LBS-J3.2	32	9.5	150	15.5	YZR160M-6	7.5	1430x1160x910	1100
LBS-J3.2B	32	12	195	15.5	YZR160M-6	7.5	1082x1014x610	536
LBS-J5	50	10	270	21.5	YZR160L-6	11	1235x1230x805	1560
LBS-J5B	50	9.5	200	21.5	YZR160L-6	11	1620x1260x945	1800
LBS-J5C	50	9.5	250	21.5	YZR160L-6	11	1235x1230x805	1800
LBS-J5D	50	15	250	21.5	YZR180L-6	15	1235x1230x805	1850
LBS-J5E	50	20	250	21.5	YZR200L-6	22	1235x1230x805	2000
LBS-J6	60	9.5	270	24	YZR180L-6	15	1235x1509x805	1800
LBS-J8	80	8	250	26	YZR180L-6	15	2090x1475x956	2900
LBS-J8B	80	9.5	350	26	YZR180L-6	15	1075x1598x985	2650
LBS-J10	100	8	170	30	YZR200L-6	22	2090x1475x956	3000
LBS-J10B	100	9.5	250	30	YZR200L-6	22	1705x2200x985	3500
LBS-J12.5	125	8	300	34	YZR225M-6	30	2880x2200x1550	5000
LBS-J13.5	135	0-5	290	28	YZR225S-8	22	2990x2363x1650	6500
LBS-J16	160	10	500	37	YZR250M2-8	37	3750x2400x1850	8800
LBS-J20	200	10	600	43	YZR280S-8	45	3950x2560x1950	9900
LBS-J25	225	9	700	48	YZR280M-8	55	4350x2800x2030	13500
LBS-J32	320	9	700	56	YZR135S-8	75	4500x2850x2100	14800
JM50	500	9	800	65	YZR315M-8	90	4930x3050x2250	19500
JM65	650	10.5	3600	64	LA8315-8AB	160	5900x4680x3200	46000

Technical Parameters of LBS-Z High-Speed Electric Winch
Model	Rated	Rated	Rope	Rope	Motor	Motor	Overall	Overall
Model	load	speed	capacity	diameter	type	power	Dimensions	weight
	KN	m/min	m	mm		KW	mm	KG
LBS-Z0.5	5	22	190	7.7	Y100L-4	3	620x701x417	200
LBS-Z1	10	22	100	9.3	Y112M-4	4	620x701x417	300
LBS-Z1.6	16	24	150	12.5	Y132S-4	5.5	945x996x570	500
LBS-Z2	20	24	150	13	Y132M-4	7.5	945x996x570	550
LBS-Z3.2	32	25	290	15.5	YZR180L-6	15	1325x1335x840	1011
LBS-Z3.2B	32	30	250	15.5	YZR200L-6	22	1900x1738x985	1500
LBS-Z5	50	30	300	21.5	YZR225M-6	30	1900x1620x985	2050
LBS-Z5B	50	25	210	21.5	YZR225M-8	22	2250x2250x1300	2264
LBS-Z8	80	25	160	26	YZR280S-8	45	1533x1985x1045	3000
LBS-Z10	100	30	300	30	YZR315S-8	55	2250x2500x1300	5100
